Portable Data Recovery Equipment-DFL-DDP USB3.0
Section 1: Number of HDD Supported by the DFL DDP Hardware

Users can connect 3 drives to SRP DDP Portable Data Recovery Equipment and 4 drives to PCIe DDP Data Recovery Equipment.

Section 2: Operating System to Install the software

Win 7, Win 8, Win 10, any of them is ok. DFL tools have unique driverless technology, no need to install device drivers.

Section 3: Biggest Advantages over Competitors

Easy to use and install on any pc, powerful with best technique support and data recovery resources.
Free data recovery training videos: http://www.youtube.com/user/datarecoverytools

Section 4:
HDD Diagnosis
Power on test; Bad Sector Scan; Single LBA read test; LBA range read test; head read test; HDD ID read test; HDD COM Terminal Test.

Section 5: HDD Erase

Zerofill the HDD/Low-level HDD Format

Section 6: Disk Image

00: Write-block is enabled as default setting;
01: Full disk sector by sector image/disk clone;
02: Partition image: data-only image or sector by sector image;
03: File image, users can select the wanted files and run disk image;
04: Data-only image;
05: Selective head image, users can image good heads first and image defective heads;
06: Multiple-pass image;
07: Customized and fully controlled image by detailed imaging settings, users can control how to handle errors, what speed to be imaged at, how different damaged hard drive should be imaged properly and differently;
08: Users can easily set the source and target drive, or setup dynamic virtual HDD as target hdd;
09: Seagate auto head map in RAM during imaging;
10: Hitachi auto translator fix during imaging;
11: Toshiba auto translator fix during imaging;
12, Auto source and target hdd error handling;
13, Western Digital Loading T2Data/190 to RAM auto for WD SMR drives, this one is specially helpful for formatted smr hdds;
14: Users can make best use of all above image methods or settings to image hdds with lots of bad sectors, weak heads at higher success rate;

Section 7: File Extraction
01, Auto read and list file directory even when mbr is damaged;
02, Users can select wanted partitions, folders and files to recover;
03, Scan lost partitions and scan MFT to get lost data back;
04, Recover files by file type;
05, Users can search the wanted files by keyword and then can easily get target files back in the shortest time;
06, Users can list files directly from hdds with many bad sectors, if only small files or several files, users can select to extract the files directly;
07, Users can easily switch from file extraction to disk image.

08, Detect bad files and save file ending with error;
09, Full controlled file extraction settings for best extraction result;
10, Selective head file extraction;
11, WD SED HDD auto decryption(before PCB 8x00xx series);
12, Export file directory tree;
13, Export file statistics report including hash values, file name, file size, access time, create time, file attribute,etc.

Section 8: Common Firmware Repair
For each hard drive brand, DDP offers quick solutions to the common firmware damaged cases.

Seagate HDD Common Firmware Repair Solutions: Busy fix, ready-then-busy fix, capacity 0 fix, MCMT fix, Dos fix, SMART fix, SIM 1002 fix, SIM1009 fix, LED fix, partial sector access fix, Load ATA/APP to RAM for old Seagate hdds, etc;

WD HDD Common Firmware Repair Solutions: NHPA, Slow fix, edit head map in RAM, load T2data/190 to RAM for WD SMR HDDs, remove password, show microcode, repair 190, wd smr hdd slow fix, etc;

Hitachi HDD Common Firmware Repair Solutions: Virtual translator to load P-list/PSHT to RAM for both 2.5” and 3.5” ARM family;

Samsung HDD Common Firmware Repair Solutions: Clear A-list, LED fix;

Toshiba HDD Common Firmware Repair Solutions: Virtual Translator, Clear G-list

Section 9: Mount/Un-mount Drives

Users can easily mount and unmounts the drives connected to Dolphin data recovery and hdd repair hardware, and users can easily read all files inside the mounted drives or can use any third-party data recovery software to scan the mounted hard drives.

There’re many Western Digital patient hard drives suffering bad sectors in the service area and users cannot operate on the firmware modules properly. At this time, if the firmware modules are corrupted, the patient drives become undetected, the data area becomes inaccessible, what to do to get the lost data back?

For some WD hdd recovery cases, users can swap the heads and the firmware area can be read properly. Some heavy drives or drives with multiple platters require adaptive rom to write to enhance heads’ read and write capabilities.

For some WD hdd recovery cases, users can use hot swap method by DFL-WD hdd repair tool to read original firmware modules and then use hot swap method again to recover lost data from original drives. The key is to find one good donor drive.

For some WD hdd recovery cases, users need to change the module size by DFL-WD firmware repair tool to bypass the bad sectors, this one is very helpful, no need to find donor head or donor hard drive;

For some WD hdd recovery cases, users can shift the bad sector firmware module by DFL-WD hdd firmware repair tool to one free good track without bad sectors and users can write the good module to the new track selected.

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

This is one Seagate ST4000VX013 hard drive firmware repair and data recovery case study for one Dolphin user in India.

Patient HDD ID:
Model number: ST4000VX013-2XG104
Family: B2
Capacity: 4TB

ST4000VX013 Patient HDD Failure Symptoms:
Clicking noises; Spin up and down; partitions lost

ST4000VX013 Required HDD Repair Tools and Data Recovery Equipment
DFL-Seagate hdd repair tool
DFL-DDP data recovery equipment

ST4000VX013 HDD Repair and Data Recovery Steps
01: Backup head adaptive module;
02: Swap heads and write donor adaptive data by DFL-Seagate hdd repair tool;
03: Backup sys35 NGlist;
04: Clear g-list and regenerate translator;
05:  Repair data offset;
06: Disable vacant active;
07: Reverse scan to get all lost partitions by DFL-DDP data recovery equipment.

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

This is one new client from New Caledonia requesting to start a data recovery business with Dolphin data recovery tools.

‘Hi,

I would like to know about the product without price on your website. Does it mean out of stock, product ended or something else ?

I’m interested by :

May you send me a quote for these products please ?

I live in New Caledonia (Pacific Island) and we can receive DHL delivery.

Thank you for your help.

Regards.’

To answer above questions or similar questions from other new clients:

Products without prices on the website don’t mean they are out of stock. For these products, users need to contact us and Dolphin team will arrange one special sales and support engineer who will give hardware details, software details, technique support details to all new clients.

Dolphin team will offer the best quote for the most suitable data recovery solution.

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

When Western Digital SMR hard drives suffer physical damage, such as head damage, platter surface scratch, surface contamination, motor stuck, parking ramp damage, etc, users get these WD SMR patient drives and we call these cases WD SMR physical data recovery cases.

Western Digital SMR Hard Drives Families:

Carmel
Charger
Spyglass II
Spyglass III
Palmer
Venicer
Etc…

Users can check the module list and see if the module 190 is available or not. If the module 190 is available, it is one WD smr drive.

After users get the physically damaged WD smr drives, users need to find one donor hdd for head swap, platter swap, platter cleaning, hdd inner parts cleaning, parking ramp swap, motor unstuck, etc. How to find one donor hdd for WD smr hard drives, find details here.

To recover lost data from WD SMR physically damaged hard drives, users can try the following important solutions:

1, Backup, edit and repair module 190;
2, Edit head map in RAM;
3, Set up head map in bitmap and image by selective heads;

Required head replacement tools, firmware repair tools and data recovery equipment:

DFL-WD HDD Repair Tool
DFL-DDP data recovery equipment
Head and Platter Swap and Clean Suite
G2 HDD Head Comb Suite.Advanced

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

Data recovery labs receive more and more data recovery cases to get lost data back from Western Digital Hitachi Helium hard drives. Among all of these Helium hdd data recovery cases, UNC firmware failure repair and recovery is very common case.

It’s not possible right now to fix the common firmware failure of UNC by the existing hdd repair and data recovery equipment in the market but from now on, Dolphin team have found one unique data recovery solution to fix the UNC common firmware failure and finally get the lost data back.

There’re many WD Hitachi helium hard drives of 8T,10T,12T,16T,etc. Users can connect these patient drives to desktop computer SATA ports and test the hdds by one software to see if they report UNC error. Users can also connect these helium patient drives to the existing hdd firmware repair hardware and see if they report UNC error.

After the UNC error is confirmed, users can use the special common fw repair solution to get the patient drives repaired and finally get the lost data back. Sometimes users may get ABR errors from the patient Helium hard drives but ABR error usually indicates the patient helium hdd head damage failure or other failures. If physical failure, users need to swap heads to continue the recovery process.

If you wish to recover lost data from Western Digital Hitachi Helium hard drives, feel free to email to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

At this Christmas Season, Dolphin team are sending all the best wishes to Dolphin users and their families. Merry Christmas!

Within 2023, Dolphin team have helped Dolphin users fix over 5300 data recovery cases by remote support and many Dolphin users have also fixed more cases by themselves!

Congratulations to All Dolphin Users for your data recovery success!

Dolphin team are adding more new data recovery solutions and latest DR techs to the existing data recovery tools and new software upgrade will be available soon in the user-only forum!

At this Christmas Season, Dolphin team wish all the best and greater success to all Dolphin users in the coming new year 2024!

You can tell us what data recovery tools, solutions you want and Dolphin team will prepare the best Christmas quote for you!

Find out all data recovery tools and solutions Dolphin team have here

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

“Greetings,

I would like a price quote on each of the tools below. My manager has a PayPal account, so if I get approval we would be using PayPal.

I see you have a recharge account for the DFL PCIe but I am interested in getting the unlimited version.

DFL PCIe unlimited version

DFL-SRP All-In-One USB3.0 Data Recovery Equipment

This is one client from Canada who wishes to grow their data recovery capabilities by adding new data recovery equipment to their data recovery labs.

Either DFL-PCIe data recovery express or DFL SRP USB3.0 data recovery equipment has many latest data recovery solutions and technologies for fixing new data loss failures of new hard drives, the following are some example solutions:

01: Seagate Rosewood HDD head map editing in ROM;
02: Repair Seagate hdd with weak heads without head map;
03: Seagate rosewood hdd partial sector access auto repair solution;
04: Many one-click solutions for common Seagate hdd failures;
05: Western Digital new drive weak head repair solution;
06: WD SMR HDD 190 auto repair and expert repair;
07: WD SMR HDD 190 auto loading to RAM;
08: WD SMR HDD easy firmware unlock on original PCB;
09: New solution to fix WD SMR Slow HDDs;
10: Hitachi partial sector access auto repair;
11: Many more, etc…

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

In many data recovery cases, users will get many invalid or corrupted files in the recovered folders. It’s not good or not professional to send all these recovered folders to the final clients(PC users asking for data recovery).

When patient drives have many bad sectors or weak heads or scratched surfaces or when the patient drives have many fragmented files and common data recovery software cannot recover and restructure all fragmented files and the recovered files could not be opened normally, users will get many invalid or corrupted files within these cases.

Dolphin DR Assistant Pro. helps a lot to detect all invalid files or corrupted files quickly and delete them quickly.

Invalid files contain the following items:

01: Suffix contains tmp, tem, temp, Ink, etc;
02: Prefix contains ?, ~,etc;
03: File name contains ? ;
04: Detect and delete desktop.ini ;
05: Detect and delete thumbs.db

File extensions supported:

jpg
png
gif
cr2
dwg
bmp
dcm
psd
tif
tiff
nef
dng
cdr
ai
crw
raf
rtf
pdf
doc
xls
ppt
xlsx
docx
pptx
mdb
accdb
rar
zip
7z
mp3
wav
amr
mp4
mov
swf
asf
3gp
flv
avi

Invalid file sizes to set;
Set to delete empty folders;
Content or File Header contains DEADDEAD;

All corrupted files will be put to one special folder DEAD_DEAD_DEAD.
Data recovery engineers use this function-‘Detect and Delete Invalid Files’ very frequently for their data recovery success.

Steps to Detect and Delete Invalid Files:

01: Select Path to detect and delete invalid files;
02: Click ‘Check’ to detect invalid files;
03: Click ‘Delete’ to delete invalid files.

Any question is welcome to sales@dolphindatalab.com or add Dolphin Skype ID: dolphin.data.lab

I’m writing to acquire some data recovery tools and clear up some doubts, are there any other service channels that work during business hours in Brazil?

DFL All-in-one Data Recovery Adapter Plus

DFL SATA to SAS Plus adapter

DFL software upgrade to a hardware

I would like to know if these items mentioned above work and have full compatibilities of DFL-DE, which is the tool I have?
