Hitachi IBM Hard Drive Firmware Repair Tool Datasheet 2024

Section 1: Repair Modes
DFL Hitachi/IBM firmware repair tool can do both hdd repair and hdd refurbishing, hdd repair is to fix firmware failures without affecting data but hdd refurbishing will remove bad sectors and destroy data.

Section 2: Number of HDD Supported by the DFL Hitachi/IBM Hardware
Users can connect 3 drives to DFL-SRP Portable Hitachi/IBM firmware repair tool and 4 drives to DFL-PCIe Hitachi/IBM firmware repair tool.

Section 3: Operating System to Install the software
Win 7, Win 8, Win 10, any of them is ok. DFL tools have unique driverless technology, no need to install drivers.

Section 4: Biggest Advantages over Competitors

Easy to use and install on any pc, powerful with best technique support and data recovery resources. Free data recovery training videos: http://www.youtube.com/user/datarecoverytools

Section 5: What Kind of Hitachi/IBM HDD Failures DFL Hitachi/IBM can Fix

01: Hitachi/IBM HDDs with many bad sectors;
02: Hitachi/IBM HDDs with ATA locked;
03: Wrongly detected Hitachi/IBM hard drives;
04: 0 capacity detected Hitachi/IBM hard drives;
05: Non-detected/Busy Hitachi/IBM hard drives;
06: Dead Hitachi/IBM hard drives, to fix this kind of dead Hitachi/IBM drives, users need to have flash programmer, donor PCB sources or physical head and platter swap tools to work with DFL Hitachi/IBM firmware repair tool;
07: Patient HDDs with weak heads;
08: Patient HDDs with forgotten password;

Tips: If users wish to recover lost data from Hitachi helium drives with UNC error, users need to email us to get detailed data recovery solution.

Section 6: Common Hitachi/IBM HDD Firmware Failures-Quick Fix

01: Sector access interruption Fix for both 2.5” and 3.5” hard drives;
02: Single weak head fix.

Section 7: ROM Operations-Firmware on PCB
01: Read/Write ROM;
02: Read/Write NVRAM;
03: Edit and Regenerate NVRAM;
04: Edit head map in NVRAM;
05: Head test;
06, Cut head

Section 8: Service Area Operations-Firmware on Platters

01: Read/write firmware modules;
02: Recover G-list translator;
03: Edit hard drive ID;
04: Remove password;
05: Unlock DVR;
06: LBA to CHS

Section 9: Defects Operations

01: View/Clear G-list, P-list;
02: View and reset smart;
03: G to P-list;
04, Scan to add to G-list;
05, Format and Zerofill.
